HEXING HXE110 - Page 69

User manual for single-phase meter
63
IEC62053-23
Mechanical parameters
Connection type
Direct or Indirect connection
Network type
1P2W or 1P3W
Terminal configuration
LLNN (1P2W DC), L1L1L2L2 (1P3W DC)
I1L1I1I2L2I2 (1P3W CT)
Weight of Meter
1.08 kg
Dimension(H x W x D)
Long terminal cover:
221mm×132mm×73mm
Mounting
Front projection mounting
Sealing
Sealing provisions for terminal with sealing screw
Cover
Terminal hole diameter
8.5mm(DC)
7.2mm(CT)
Terminal cover
Long type terminal cover
Meter Cover material Opaque PC+GF
Meter Base material Opaque PC+GF
Terminal Cover material Transparent PC
Display parameters
Default display range
0~999999.99 kWh/kvarh
Display mode
LCD
