HEXING HXE110 - Arithmetic of Load Profile Capacity

User manual for single-phase meter
16
Last average value of power factor L1
5
Last average value of power factor 5
Last average value of import active power
5
Last average value of export active power 5
Last average value of import reactive power
5
Last average value of export reactive power 5
Last Maximum value of voltage L1
5
Last Maximum value of current L1 5
Last Maximum value of power factor L1
5
Last Maximum value of power factor 5
Last Maximum value of import active power
5
Last Maximum value of export active power 5
Last Maximum value of import reactive power
5
Last Maximum value of export reactive power 5
Last Minimum value of voltage L1
5
Last Minimum value of current L1 5
Last Minimum value of power factor L1
5
Last Minimum value of power factor 5
Last Minimum value of import active power
5
Last Minimum value of export active power 5
Last Minimum value of import reactive power
5
Last Minimum value of export reactive power 5
Credit(only for prepaid mode meter)
5
8.3 Arithmetic of load profile capacity
The days of storage capacity date calculation formula is as follows:
Day = Profile total bytes /capture object bytes * capture period(s)/86400
Example:
 Capacity of load profile 1: 228kbyte
 Capture period: 15min
 Capture object: clock (14 byte), status word (2 byte), import active energy (5 byte),
import active energy tariff 1(5 byte), import active energy tariff 2 (5 byte), import active
energy tariff 3 (5 byte), import active energy tariff 4(5 byte)
 Storage Days: Days=228*1024/(14+2+5+5+5+5)*900/86400=67 days
