HEXING HXE110 - 13.2 Tamper Event; 13.3 Relay Control Event

User manual for single-phase meter
25
13.2 Tamper event
These events are all about electricity tampering,
Record format: event code and occurring time.
Up to 100 entries of events can be recorded
Tab13.1.2 Tampering event
Code Corresponding event Judgment
40 Terminal cover open Terminal cover being open
41 Terminal cover closed Terminal cover being closed
42
Appearance of strong magnetic
field
Appearance of strong magnetic field
43 Disappearance of large magnetic
field
Disappearance of strong magnetic field
44
Meter cover open
Meter cover being open
45
Meter cover closed
Meter cover being closed
46
Association authentication
failure for several times
Association authentication fails for 3 times
47 Module cover open Module cover being open
48
Module cover closed
Module cover being closed
49
Meter box cover open
Meter box cover being open
50 Meter box cover closed Meter box cover being closed
68 Bypass start Bypass is start
69 Bypass end Bypass is end
13.3 Relay control event
These events are about relay control.
Record format: event code and occurring time, overload threshold when the event occurs. .
Up to 100 entries of such events can be recorded.
Tab13.1.3 relay control event
Code
Corresponding event
Judgment
60
Manual disconnection
manual disconnect is executed
61
Manual connection
manual reconnect is executed
62 Remote disconnection remote disconnect is executed
63 Remote connection remote disconnect s executed
64 Local disconnection Local disconnection is executed
65 Limiter threshold exceeded overload Limiter is executed
66
Limiter threshold ok
Limiter threshold is ok
