Product description
Page 17
heyer_LUVAR_UserManual_EN-3_CRev-1
1 LUVAR respiratory therapy device
2 Touch Screen
Displays device information, selection and navigation within the menus and
sets parameters by touching the screen
3 Rotary knob
Selection and navigation within the menus and setting parameters
4 Sensor keys for humidifier and ramp function
5 Power supply connector for humidifier
Supplies electrical voltage to the humidifier
6 IR data interface
Used for communication between the respiratory therapy device and humid-
ifier
7 Device air outlet
Connection for the breathing tube system or the respiratory humidifier
8 Humidifier housing
9 Water tank
10 Fill level markings
11 Humidifier air outlet
Connection for the breathing tube system
12 Humidifier air inlet
