HD33523
Read manuals and labels
Before operating or working on this outboard motor:
Read this manual.
Read any manuals supplied with the boat.
Read all labels on the outboard motor and the boat.
If you need any additional information, contact your Hidea dealer.
HD33832
Warning labels
If these labels are damaged or missing, contact your Hidea dealer for replacements.
F15, F20
10
1
2
3
ZMU05739
21
