Alert system
gine and check the cooling water inlets:
Check trim angle to be sure that
the cool- ing water inlet is submerged.
NOTICE
Do not continue to operate the engine if
a alert device has activated. Consult
your Hidea dealer if the problem cannot
be located and corrected.
Overheat alert
This engine has an overheat-alert device. If
the engine temperature rises too high, the
alert device will activate.
The engine speed will
automatically de- crease to about 2000 r/
min.
The overheat-alert indicator will
light or blink.
The buzzer will sound (if
equipped on the tiller handle, remote
control box, or main switch panel).
If the alert system has activated, stop the
en-
Check the cooling water inlet for
clogging.
Low oil pressure alert
If the oil pressure drops too low, the alert de-
vice will activate.
The engine speed will automatically
de- crease to about 2000 r/min. If
equipped with a low oil pressure-alert
indicator, it will light or blink.
The buzzer will sound (if equipped on
the tiller handle, remote control box, or
main switch panel).
