port side “A”.
To decrease resistance, turn the lever to the
starboard side “B”.
UP
DN
ZMU05579
Do not overtighten the friction adjuster. If
there is too much resistance, it could be
difficult to
steer,
which could result in an
accident.
If the resistance does not increase even
when the lever is turned to the port side “A”,
make sure that the nut is tightened to the
specified torque.
TIP:
For instructions on using the power tilt
switch, see pages 57 and 60.
Steering friction adjuster
A friction device provides adjustable resis-
tance to the steering mechanism, and can
be set according to operator preference. An
ad- juster lever is located on the bottom of
the tiller handle bracket.
To increase resistance, turn the lever to the
1. Nut
TIP:
Steering movement is blocked when
the
30
