Hidea F15 User Manual

2
9
8
3
7
WARNING
Components
F15H, F20MHA
1
10
11
12
13
17
21
20
18
19
22
4
5
16
15
14
1. Top cowling
2. Cowling lock lever
3. Drain screw
4. Anti-cavitation plate
5. Trim tab
6
21. Flushing device
22. Fuel tank*
HD25802
Fuel tank
ZMU07413
6. Propeller
7. Cooling water inlet
8. Trim rod
9. Clamp bracket
10. Manual starter handle
11. Alert indicator
12. Gear shift lever
13. Engine stop button/Engine shut-off switch
14. Throttle grip
15. Throttle friction adjuster
16. Clip
17. Tilt lock lever
18. Clamp screw
19. Restraint cable attachment
20. Steering friction adjuster
If your model was equipped with a portable
fuel tank, its function is as follows.
EWM00020
The fuel tank supplied with this engine is
its dedicated fuel reservoir and must not
be used as a fuel storage container.
Com- mercial users should conform to
relevant licensing or approval authority
regula- tions.
