Higen FDA7002EX User Manual

3. Parameter setting
3-40
12
PCWRUN
CCW revolution status output
13
NCWRUN
CW revolution status output
14
ALARM
Alarm generation status output
15
A_CODE0
Alarm code-0 output
16
A_CODE1
Alarm code-1 output
17
A_CODE2
Alarm code-2 output
18
A_CODE3
Alarm code-3 output
19
WARNING
Warning status output
(OFF when warning occurs and ON when normal operation)
<FDA7000/7000-H Series>
20
EXT DB
External DB Control Signal Output
(P02-09 DB mode setting, P02-39 output type selection)
21
START/STOP
Output status of STOP input
* This function applies only to the FDA7000EX model.
< FDA7000EXD>
20
START/STOP
Output status of STOP input
* This function applies only to the FDA7000EX model.
23
EXT DB
External DB Control Signal Output
(P02-09 DB mode setting, P02-39 output type selection)
25
SETUP1
Use torque control mode internal setting function
(Can only be entered in P08-01 menu)
26
SETUP2
Use speed control mode internal setting function
(Can only be entered in P08-01 menu)
27
SETUP3
Use position control mode internal setting function
(Can only be entered in P08-01 menu)
28
SETUP4
Use speed/torque multi control mode internal setting function
(Can only be entered in P08-01 menu)
29
SETUP5
Use speed/position multi control mode internal setting function
(Can only be entered in P08-01 menu)
30
SETUP6
Use position/torque multi control mode internal setting function
(Can only be entered in P08-01 menu)

Higen FDA7002EX Specifications

General

Brand	Higen
Model	FDA7002EX
Category	Servo Drives
Language	English
