Appendix D
94 Studio Command Series User Manual
PRST
(cont.)
EDIT
(cont.)
SN01 -
SN16
(cont.)
PAN
-49.9–
+49.9
select a pan value from -49.9% to +49.9% of the pan range
TILT
-49.9–
+49.9
select a tilt value from -49.9% to +49.9% of the tilt range
COLC
Full Speed Mode
CON
continuous—select exact positioning at any point on the color
wheel
CYCL cycles through colors with cyan channel setting cycle speed.
RND
random—perform random color chase of 12 factory-selected
colors using the three color wheels (speed set by cyan
channel)
MSpeed Mode
MCON
continuous—select exact positioning at any point on the color
wheel
MCYC cycles through colors with cyan channel setting cycle speed.
MRND
random—perform random color chase of 12 factory-selected
colors using the three color wheels (speed set by cyan
channel)
CYAN
D000 -
D255
select an exact position on the cyan color wheel from 0 (D000)
to full saturation (D255) when COLC = CON
L000 -
L255
sets speed of CYCL mode from stop (L000) to full speed
(L255)
N000 -
N255
sets speed of RND mode from stop (N000) to full speed
(N255)
MAGN
D000 -
D255
select an exact position on magenta color wheel from 0 (D000)
to full saturation (D255)
CYCL
No function in CYCL or RND COLC modes.
RND
YELW
D000 -
D255
select an exact position on yellow color wheel from 0 (D000) to
full saturation (D255)
CYCL
No function in CYCL or RND COLC modes.
RND
ZOOM
Z000–
Z255
select a zoom value for a beam angle from 18° (Z000) to 33°
(Z255)
MSPD
252.7–
0.15
select a motor movement time in decimal seconds, from slow
(252.7) to fast (0.15)
0.15–
252.7
select a motor movement time in decimal seconds, from fast
(0.15) to slow (252.7)
MACR
MCOF set all macro options off
P00-
P56
pan sweep macro from small to large
TO macros off
T00–
T56
tilt sweep from small to large
CO macros off
C00–
CC34
clockwise circle macro
Level 1 Level 2 Level 3 Level 4 Level 5 Description
