Appendix D
Studio Command Series User Manual 95
PRST
(cont.)
EDIT
(cont.)
SN01-
SN16
(cont.)
MACR
CCO macros off
CC00–
CC34
counterclockwise circle macro
MCOF set all macro options off
XFAD
X 0.1 -
X 9.9
select the DIM and FCUS construct’s crossfade time in
increments of 0.1
X 10 -
X166
select the DIM and FCUS construct’s crossfade time in
increments of 1
DLAY
D 0.1 -
D 9.9
select the scene delay time in increments of 0.1
D 10 -
D166
select the scene delay time in increments of 1
TIME
SEC
select seconds as the units of time used for the XFAD and
DLAY constructs
MIN
select minutes as the units of time used for the XFAD and
DLAY constructs
TIME
(cont.)
HOUR
select hours as the units of time used for the XFAD and DLAY
constructs
ZERO OK?
erase any programming of the current scene by voiding all
construct values / mark the end of the loop
COPY
FROM
FA01 -
FA16
select a user A scene to copy from (source scene)
FA01 -
FA16
select a user B scene to copy from (source scene)
TO
TA01 -
TA16
select a user A scene to copy to (destination scene)
TB01 -
TB16
select a user B scene to copy to (destination scene)
CAPT
SN01 -
SN16
select a scene to capture a pre-programmed scene to (from
your DMX controller)
DFLT OK?
enable the factory-programmed preset scene sequence (self-
demo) / erases any preset scenes previously programmed
SET
SEND send all presets in current user
FACT
ON set factory defaults on
OFF set factory defaults off
SWAP
ON set pan/tilt swap on
OFF set pan/tilt swap off
T/IN
ON set tilt invert on
OFF set tilt invert off
P/IN
ON set pan invert on
OFF set pan invert off
DSPL
ON set the LED display on
OFF set the LED display off
DIM dim the LED display
D/IN
ON select inverted LED display orientation
OFF select normal LED display orientation
Level 1 Level 2 Level 3 Level 4 Level 5 Description
