Appendix D
96 Studio Command Series User Manual
MODE
LMPL
ON enable lamp hour warning message
OFF disable lamp hour warning message
DLOS
LONG shutter will remain open until shutdown if DMX data is lost
SHRT
shutter will close one second after DMX data is lost
Note: In Studio Command H Models, the lamp will douse one
second after DMX data is lost.
USER
A select user A settings
B select user B settings
COPY
PRST
A →B copy user A presets to user B
B →A copy user B presets to user A
SETT
A →B copy user A settings to user B
B →A copy user B settings to user A
ALL
A →B copy user A presets and settings to user B
B →A copy user B presets and settings to user A
XLD
crossload fixture software to other Studio Command fixtures
on the link
TEST
HOME home the fixture
LAMP
ON strike the lamp
OFF extinguish the lamp
BOOT copy the boot sector
SELF
ALL self test all constructs
PAN self test pan movement
TILT self test tilt movement
CYAN self test cyan color wheel movement
MAGN self test magenta color wheel movement
YELW self test yellow color wheel movement
ZOOM self test zoom movement
SHUT self test shutter strobe movement
DIM self test dim flag movement.
S/UP place the fixture in setup mode for mechanical homing
DISP self test the LED display
ENCD
ON restore pan and tilt encoder operation
OFF disable pan and tilt encoder operation
CODE Factory use only
Level 1 Level 2 Level 3 Level 4 Level 5 Description
