INFO
SENS
TILT
view whether the tilt sensor is obstructed (“ON”) or is not
obstructed (“OFF”)
PAN
view whether the pan sensor is obstructed (“ON”) or is not
obstructed (“OFF”)
TPOS view the tilt position encoder status
PPOS view the pan position encoder status
UNUM Customer Service use only
DMX
DMX Values displayed when standard protocol is selected
FIXT
BRKS view the number of DMX breaks
FE view the number of DMX framing errors
OV view the number of DMX overruns
STRT view the DMX start code value
PANH view the DMX high resolution pan value
TLTH view the DMX high resolution tilt value
TLTL view the DMX low resolution tilt value
COLC view the DMX color control channel value
CYAN view the DMX cyan color wheel position value
MAGN view the DMX magenta color wheel position value
YELW view the DMX yellow color wheel position value
ZOOM view the DMX zoom lens position value
SHUT view the DMX shutter strobe value
DIM view the DMX shutter dim flag value.
MSPD view the DMX MSpeed time value
MACR view the DMX macro value
CNTL view the DMX control channel value
DATA
C001 -
C512
view the DMX data for the selected DMX channel
TEMP
PCB view the current temperature at the logic board (C)
HEAD view the current internal head temperature (C)
F/RS
reset fixture hours to zero (press and hold the <Enter> button
for five seconds to change the value)
F/HR view current number of fixture hours
L/RS
reset lamp hours to zero (press and hold the <Enter> button
for five seconds to change the value)
L/ST view the current number of lamp strikes
L/HR view the current number of lamp hours
VER view the fixture’s software version
