CHAPTER 6
Troubleshooting
Studio Command Series User Manual 67
PRGM
TIME
One or more fixtures on the data link has
failed to program the FlashROM in a suitable
amount of time.
Attempt another software crossload (see
Crossloading Fixture Software (XLD) on
page 32).
Contact High End Systems customer support
if problem continues.
TMP1
LOST
The fixture cannot detect the temperature
readback from the thermometer on the PCB.
Contact High End Systems customer support.
TILT
ENCD
Fixture has detected a tilt error and cannot
correct its position due to a:
• physical obstruction
• broken belt
• bad tilt encoder or encoder wheel
• a broken wire connecting the encoder to the
logic board.
Remove the object (externally or internally)
that is blocking the fixture’s tilt movement and
home the fixture (see
Homing the Fixture
(HOME)
on page 33).
Contact High End Systems customer support
if problem continues.
TILT
SENS
Fixture cannot find the tilt home slot due to a:
• broken belt
• faulty motor or motor driver
• broken wire connecting the sensor or tilt
motor to the logic board
• bad sensor.
Contact High End Systems customer support.
UPLD
The software upload or crossload was
interrupted and the fixture is held in boot
mode.
Make sure the fixture is properly connected to
both data and power cables, then attempt
another software crossload (see
Crossloading
Fixture Software (XLD)
on page 32).
Contact High End Systems customer support
if problem continues.
Display
Message
Problem Solution
