Appendix A
Studio Command™ DMX Protocol
Studio Command Series User Manual 77
10
Shutter
(cont.)
Lamp Assisted Strobes (Accessed when the Control channel range = 134-137)
The shutter functions are the same as in the normal shutter function range.
Periodic strobes, random random and random synchronous strobes are lamp
assisted.
Lamp Functions. (Accessed when the Control channel range = 138-141)
For lamp boost effects, the lamp is boosted above the 700 Watt level for the
specified period of time. The lamp is also boosted during the lightning effects.
Before another boost or lightning effect can occur, the shutter channel must be
moved to either closed or open, or the control channel must be moved outside
the lamp function range.
Boost functions to black will boost the lamp for the specified time then close the
shutter. Boost functions to white will boost the lamp for the specified time, then
leave the shutter open with the lamp dimmed.
When lightning functions are selected, the dim channel scales the overall
brightness of the lightning stroke. Dim at 255 will yield maximum brightness.
Close 0-23 0-9 00-17
Periodic lamp strobes 24-49 9-19 18-31
Random random lamp strobes 50-75 20-29 32-4B
Synchronous random lamp strobes 76-101 30-40 4C-65
Boost lamp1.0 second, black 102-105 40-41 66-69
Boost lamp .75 second, black 106-109 42-43 6A-6D
Boost lamp .66 second, black 110-113 43-44 6E-71
Boost lamp .5 second, black 114-117 45-46 72-75
Boost lamp .33 second, black 118-121 46-47 76-79
Boost lamp .25 second, black 122-127 48-50 7A-7F
Boost lamp 1.0 second, white 128-131 50-51 80-83
Boost lamp .75 second, white 132-135 52-53 84-87
Boost lamp .66 second, white 136-139 53-55 88-8B
Boost lamp .5 second, white 140-143 55-56 8C-8F
Boost lamp .33 second, white 144-147 56-58 90-93
Boost lamp .25 second, white 148-153 58-60 94-99
Lightning strike 1 154-157 60-62 9A-9D
Lightning strike 2 158-161 62-63 9E-A1
Lightning strike 3 162-165 64-65 A2-A5
Lightning strike 4 166-169 65-66 A6-A9
Lightning strike 5 170-173 67-68 AA-AD
Lightning strike 6 174-179 68-70 AE-B3
To be determined, default black 180-231 71-91 B4-E7
Open 232-255 91-100 E8-FF
Lamp Dimming only. (Accessed when the Control Channel range = 146-149)
The shutter functions are the same as the normal shutter function range.
Dimming is accomplished electronically, lowering the lamp power. Dimming will
not go to black. Strobes are mechanical and will go to black.
Channel Parameter Description
Value
(dec.)
Value
(%)
Value
(hex)
