Appendix A
Studio Command™ DMX Protocol
78 Studio Command Series User Manual
11 Dim
Close 0 0 00
Open 255 100 FF
12 MSpeed
Disable 0-3 0-1 00-03
Longest (252.7 sec.) 4 2 04
Shortest (0.15 sec.) 255 100 FF
13
Macro
(Note 1)
Macro Off 0-5 0-2 00-05
Pan sweep, small to large angle 6-62 2-24 06-3E
Macro Off 63-65 25-25 3F-41
Tilt sweep, small to large angle 66-122 26-48 42-7A
Macro Off 123-125 48-49 7B-7D
Clockwise circle, small to large 126-160 49-63 7E-A0
Macro Off 161-163 63-64 A1-A3
Counterclockwise circle, small to large 164-198 64-78 A4-C6
Reserved 199-255 78-100 C7-FF
14 Control
The Control channel should not be crossfaded.
Safe (disables all Control settings) 0-9 0-4 00-09
Pan & Tilt MSpeed Off 10-19 4-7 0A-13
Set Shutter channel to 0 for access to the following commands.
Display Off 20-28 8-11 14-1C
Display Dim 30-38 12-15 1E-26
Display Bright 40-48 16-19 28-30
Home 60-68 24-27 3C-44
Lamp On 80-88 31-35 50-58
Lamp Off 90-98 35-38 5A-62
Shutdown (send for 5 seconds) 110-130 43-51 6E-82
Lamp Functions
Lamp assisted strobes (Periodic and Random
strobe functions are lamp assisted. Ramp functions
are not lamp assisted.)
134-137 53-54 86-89
Lamp functions (modifies the shutter channel) 138-141 54-55 8A-8D
Lamp/mechanical dimming (Lamp output will vary
from a minimum to 700 Watts as the mechanical
dimming ranges from 0-100%)
142-145 56-57 8E-91
Lamp only dimming (Electronic dimming only from
a minimum to 700 Watts.)
146-149 57-58 92-95
To be determined 150-255 59-100 96-FF
Channel Parameter Description
Value
(dec.)
Value
(%)
Value
(hex)
