HikRobot VC3000Pro Series User Manual

VC3000Pro Series Vision Controller User Manual
3
No.
Name
Description
11
GND Hole
It is used to connect ground wire.
12
USB 2.0 Interface
It is used to connect USB flash drive, portable HDD, etc.
13
Serial Port
It is used for serial communication.
14
Screw Hole for Serial Port
It is used to fix serial port.
15
Remote Switch Interface
It is used to power on/off the device remotely.
16
Screw Hole for Remote
Switch Interface
It is used to fix remote switch interface.
17
USB 3.0 Interface
It is used to connect USB flash drive, portable HDD, etc.
18
Audio Interface
It is used to transmit audio signal.
19
Screw Hole
It is used to fix the device, and you should use M3 or M4
screw.
20
Snap Fit Component
It is used to connect extended module.
21
Connection Hole
It is used to connect main module with extended module.
22
Connection Plug
It is used to connect the plug of extended module.
2.2 Extended Module Appearance
The device can be installed with light source and IO extended modules.
Note
Up to two light source extended modules or two IO extended modules can be installed to the device
at the same time.

HikRobot VC3000Pro Series Specifications

General

Brand	HikRobot
Model	VC3000Pro Series
Category	Controller
Language	English
