VC3000Pro Series Vision Controller User Manual
16
Figure 4-9 mSATA Interface
4.1.5 Extended Slot
The main module has a PCIe x16 extended slot that is used to connect frame grabber, graphics
card, or motion card, etc.
Note
The extended slot may differ by device model, and the actual product you purchased shall prevail.
Extended Slot
mSATA Interface
Figure 4-10 Extended Slot
