4.1.8 Memory Slot
The main module has two memory slots, and it is inserted with a 8 GB memory ram by default.
You can add extra memory ram according to actual demands.
Figure 4-13 Memory Slot
4.2 Extended Module Interface
4.2.1 Light Source Extended Module Interface
The light source extended module provides light source trigger interface, and different external
devices can control the light source via this trigger interface and SDK or Demo.
Note
Wiring may differ when using different external devices to control the light source trigger interface.
