VC3000Pro Series Vision Controller User Manual
8
Figure 3-2 Horizontal Mounting of Main Module
3.3 Install Extended Module
Before You Start
●
Make sure that the device in the package is in good condition and all the assembly parts are
included.
●
Make sure that all the related equipment is powered off during the installation.
Steps
1. Install the extended module to the main module.
Note
Make sure the corresponding parts of the main module are correctly connected with those of
extended module.
