HIKVISION DS-6900UDI Series User Manual

DS-6900UDI Series HD Video and Audio Decoder User Manual
DS-6900UDI Decoder Us er Manua l
30
Set LED Resolution

The value of LED width and height cannot exceed the output resolution you select.

The supported min. value of LED width × height of HDMI output is 288 × 288 and the max.
value is 1920 × 1080.
Check the checkbox of Batch Configuration to set the same configuration for other outputs
with same signal source.
Batch Configuration
Click OK to save the settings.
Right click one of the HDMI signal sources and click Output Mode Configuration to pop up
the interface below.

HIKVISION DS-6900UDI Series Specifications

General

Brand	HIKVISION
Model	DS-6900UDI Series
Category	Media Converter
Language	English
