DS-6900UDI Series HD Video and Audio Decoder User Manual
DS-6900UDI Decoder Us er Manua l
64
Enter the Video Wall interface, select the LED screen and click the button to open the
window via coordinate.
Open the Window via Coordinate (2)
Select the Device Name from the drop down list, and input the X-Coordinate, Y-Coordinate,
Width and Height.
Click OK to save the settings and the opened window will be displayed on the video wall.
You cannot open the window via coordinate across both the non-LED and LED screens.
You cannot edit the X-Coordinate of LED Area and Y-Coordinate of LED Area.
The X-coordinate and Y-coordinate are relative output channel coordinates.
Managing Decoding
Right-click on a playing window to activate the decoding management menu as shown below.
The menu differs depending on the devices.
