DS-6900UDI Series HD Video and Audio Decoder User Manual
DS-6900UDI Decoder Us er Manua l
5
Description of DS-6916UDI Front Panel
No.
LED Indicator & Interface
Connections
1
VGA IN
VGA input signal indicator
2
DVI IN
DVI input signal indicator
3
POWER
Power indicator
4
G2
10/100/1000 Mbps Ethernet interface 2
5
OPT2
10/100/1000 Mbps optical interface 2
6
USB
USB 2.0 interface
7
G1
10/100/1000 Mbps Ethernet interface 1
8
OPT1
10/100/1000 Mbps optical interface 1
9
RS-232 serial interface
Connect to RS-232 devices, e.g., PC etc.
Rear Panel
Rear Panel of DS-6901UDI
Rear Panel of DS-6901UDI
Description of DS-6901UDI Rear Panel
Interface
Connections
1
LINE IN/OUT
Two-way audio input/output, 3.5 mm connector
2
RS-232 serial interface
Connect to RS-232 devices, e.g., PC.
3
LAN
10/100/1000 Mbps Ethernet interface
4
RS-485 serial interface
Connect to RS-485 devices, e.g., keyboard.
