DS-6900UDI Series HD Video and Audio Decoder User Manual
DS-6900UDI Decoder Us er Manua l
6
 Rear Panel of DS-6904UDI
Rear Panel of DS-6904UDI
Description of DS-6904UDI
 Rear Panel of DS-6908UDI
3 4
5
6 7
1
2
8
5
Alarm in
8 alarm inputs
Alarm out
8 alarm outputs
6
Power supply
12 VDC power input
7
GND
No.
Interface
Connections
1
Audio output
BNC connector
2
HDMI video output
HDMI output of decoded video
3
CVBS video input
CVBS input of decoded video
4
DVI video input
DVI input of decoded video
5
HDMI video input
HDMI input of decoded video
6
Power switch
Power on or power off the device
7
Power
Power indicator
8
GND
