HIKVISION DS-6900UDI Series User Manual

DS-6900UDI Series HD Video and Audio Decoder User Manual
DS-6900UDI Decoder Us er Manua l
54
Configuring Video Wall
Adding a Video Wall
Click Video Wall tab to enter the Video Wall interface.
You can use the default video wall layout or click and select Add Video Wall to enter the
Add Video Wall interface.
You can modify the default video wall, but not allowed to delete it.
Add Video Wall
Input the Video Wall Name, and the number of windows in row and column text fields.
Click Add to add the video wall.

Up to 5 video walls can be added to the client software.

The range of the row number is between 1 and 16, and column number between 1 and
20.
Drag the output channels from the left side list to link the decoding output to the video wall.

HIKVISION DS-6900UDI Series Specifications

General

Brand	HIKVISION
Model	DS-6900UDI Series
Category	Media Converter
Language	English
