HIKVISION DS-6900UDI Series User Manual

DS-6900UDI Series HD Video and Audio Decoder User Manual
DS-6900UDI Decoder Us er Manua l
69
Configuring Window
 Configuring Window Division Mode
Purpose
You can set the window division mode of the decoding window.
Drag a camera from the left-side list to the display window of the video wall, or you can
open a window.
Click to expand the menu.
Click to select the window division mode. 1/2/4/6/8/9/12/16/25/36 modes are
selectable.
 Zooming in/out Roaming Windows
You can double click the roaming window to zoom in or out. Refer to Chapter 6.4.8 Zooming in/out
Roaming Windows for reference.
 Configuring Window Parameters
Purpose
You can set the window as the alarm window to display the video triggered by event or alarm input
on the video wall. You can also set the decoding delay and image parameters.
Drag the camera from the left-side list to the display window of the video wall, or you can
open a window if supported.
Click Window Configuration to pop up the configuration dialog box.
Window Configuration

HIKVISION DS-6900UDI Series Specifications

General

Brand	HIKVISION
Model	DS-6900UDI Series
Category	Media Converter
Language	English
