DS-6900UDI Series HD Video and Audio Decoder User Manual
DS-6900UDI Decoder Us er Manua l
29
Batch Configuration
Click OK to save the settings.
Configuring HDMI Output
Right click one of the HDMI signal sources.
HDMI Decoding Output
Click Resolution Configuration to enter the interface below.
Resolution Configuration
Select the Output Mode and set the corresponding parameters. You can select LCD and LED.
 LCD
1. Select the Output Mode to LCD.
1. Select the resolution from the LCD Resolution drop-down list.
Set LCD Resolution
 LED
1. Select the Output Mode to LED.
1. Input the LED Width and LED Height in the corresponding text fields.
