User Manual of DS-7200-SH/SV&DS-7300-SH Series DVR
41
Steps:
1. Enter the PTZ Control interface.
Menu>Camera>PTZ>More Settings
2. Select patrol number.
3. Select the under Patrol option box to add key points for the patrol.
Figure 4.6 PTZ- Add Key Point
4. Configure key point parameters, such as the key point No., duration of staying for one key point and
speed of patrol. The key point is corresponding to the preset. The Key Point No. determines the order at
which the PTZ will follow while cycling through the patrol. The Duration refers to the time span to stay
at the corresponding key point. The Speed defines the speed at which the PTZ will move from one key
point to the next.
Figure 4.7 Key point Configuration
5. Click OK to save the key point to the patrol.
Repeat the above steps to add more key points.
You can also delete all the key points by clicking the trash icon
