User Manual of DS-7200/7300/8100 Series DVR
32
Figure 2. 5 Network Configuration
The DS-7204/7208/7216 models provide one 10M/100Mbps self-adaptive network interface, the
DS-7224/7232, DS-7300 and DS-8104/8108 models provide one 10M/100M/1000Mbps self-adaptive
network interface, and the DS-8116/8124/8132 models provide two10M/100M/1000Mbps self-adaptive
network interfaces.
6. Click Next button to enter the advanced network settings window.
7. Configure the advanced network parameters, including the server port, HTTP port, RTSP port, UPnP,
EZVIZ Cloud P2P and DDNS settings.
Figure 2. 6 Advanced Network Configuration
8. Click Next button to enter the HDD Management window, shown in Figure 2.7.
To initialize the HDD, click the Init button. Initialization removes all the data saved in the HDD.

HIKVISION DS-7200 Specifications

General

Hard Disk	1 SATA interface
Video Input	4/8/16 channels
Video Output	1 HDMI, 1 VGA
Audio Output	1 channel, RCA
HDD Capacity	Up to 6TB
Network Protocols	TCP/IP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, UPnP
Network Interface	1 RJ45 10M/100M adaptive Ethernet interface
USB Interface	2 USB 2.0
Working Temperature	-10 °C to 55 °C (14 °F to 131 °F)
Video Compression	H.264+
Encoding Resolution	1080p/720p/4CIF/CIF
