User Manual of Digital Video Recorder
108
The files stored in the extrenal device are listed in the right-side list.
You can click the Refresh button to refresh the file list.
3. Select a record file and click to play it.
Figure 6. 23 Interface of External File Playback
6.1.8 Playing Back Frame Extracting Record
Purpose:
If there are frame extracting record files existing in the HDD, you can search and play back them. In this section,
we use the interface of DS-9100HFI-RT series as example to describe the following settings.
Frame extracting record is supported by DVR series only.
The frame extracting record is with low bitrate and the frame rate is 1 fps.
Steps:
1. Enter the Playback interface, and check checkbox to select the frame extracting mode.
Menu>Playback
