User Manual of Digital Video Recorder
164
Directory: In the Directory field, you can select the Root directory, Parent directory and secondary
directory. When the Parent Directory is selected, you have the option to use the Device Name, Device No.
or Device IP for the name of the directory, or you can customize the directory name; and the when the
Secondary Directory is selected, you can use the Camera Name or Camera No. as the name of the
directory, or you can customize the directory name.
If you want to modify the Device Name, Device No., Device IP or Camera Name, please enter the
corresponding interface to modify.
6. Click Apply to save and exit the interface.
Please make sure the remote FTP server has been started up before setting the FTP parameters.
9.2.5 Configuring SNMP Settings
Purpose:
You can use SNMP protocol to get device status and parameters related information.
Steps:
1. Enter the Network Settings interface.
Menu > Configuration > Network
2. Select the SNMP tab to enter the SNMP Settings interface.
Figure 9. 21 SNMP Settings Interface
3. Check checkbox to enable SNMP.
4. Configure the SNMP settings.
Figure 9. 22 Configure SNMP Settings
5. Click Apply to save and exit the interface.
Before setting the SNMP, please download the SNMP software and manage to receive the device information
via SNMP port. By setting the Trap Address, the device is allowed to send the alarm event and exception
message to the surveillance center.
