User Manual of Digital Video Recorder
46
3.2.4 Quick Setting Toolbar in Live View Mode
Click on the live view window, a quick setting toolbar will be shown on the bottom as follows:
The Live View Strategy icon and Information icon are only available for network cameras.
Figure 3. 3 Quick Setting Toolbar
Table 3. 6 Description of Quick Setting Toolbar Icons
Icons
Description
Icons
Description
Icons
Description
/
Enable/Disable
Record
Instant Playback
/
Mute/Audio on
Capture
PTZ Control
Digital Zoom
Image Settings
Live View
Strategy
Information
Close
Instant Playback only shows the record in last five minutes. If no record is found, it means there is no
record file during the last five minutes.
Digital Zoom function makes the camera zoom in on selected area, thus to get a close view of the picture.
You can click-and-drag the mouse to select the area for zooming in.
Figure 3. 4 Digital Zoom
Image Settings icon can be selected to enter the Image Settings menu.
For Analog Cameras:
Four modes are selectable according to the real situation:
Standard: for general lighting conditions (default).
Indoor: the image is relatively smoother.
