User Manual of Digital Video Recorder
179
9.4.3 Checking Network Status
Purpose:
You can also check the network status and quick set the network parameters in this interface.
Dual NIC is not supported by DS-7200HWI-SV series. We use the interface of DS-9100HFI-ST series (unless
otherwise stated) as example to describe the following settings.
Steps:
1. Enter the Network Traffic interface.
Menu > Maintenance > Net Detect
2. Click the Network Detection tab to enter the Network Detection interface.
3. Click Status to get the network status.
Figure 9. 53 Checking Network Status
If the network is normal the following message box pops out.
Figure 9. 54 Network Status Checking Result
If the message box pops out with other information instead of this one, you can click Network to show the
quick setting interface of the network parameters.
