User Manual of Digital V
ideo Recorder
193
Figure 10. 25
Arra
y Settings Interface
2.
S
elect an array and clic
k
to delete the array.
Figure 10. 26
Co
nfirm Array Deletion
3.
In
the pop-up message box, click
Yes
to confirm the array deletion.
Deleting array will cause to delete all the data in the array
.
193
