User Manual of Digital Video Recorder
68
3. Encoding Parameters for Sub-stream
1) Click the Substream tab to configure the parameters of sub-stream, such as stream type, resolution,
frame rate, etc.
Figure 5. 6 Sub-stream Encoding
2) Click Apply to save the settings.
3) Optionally, you can click Copy to copy the settings to other analog channels if needed.
4. Encoding Parameters for Capture
1) Click the Capture tab to configure the capture parameters, such as resolution, picture quality, etc.
Figure 5. 7 Capture Encoding
2) You can configure the continuous and event parameters separately.
3) Click Apply to save the settings.
4) Optionally, you can click Copy to copy the settings to other analog channels if needed.
The interval is the time period between two capturing actions and the interval can be set as 1s, 2s, 3s, 4s,
5s, 10min, 30min, 1h, 12h and 24h. You can configure all the parameters on this menu on your demand.
5. Configure the overwrite mode of the HDD (Menu>Record>Advanced>Advanced). Check checkbox
to enable the overwrite mode, and then the record files will be overwritten when the HDD becomes full.
Otherwise, the recording will stop when the HDD becomes full.
Figure 5. 8 Overwrite Mode
6. Configure the two-way audio record (Menu>Record>Advanced>Two-way Audio). Check checkbox
to enable the two-way audio record and select the camera from the drop-down list. Then, the two-way
audio record will be bound to the selected camera as the audio input.
