User Manual of Digital Video Recorder
72
6) Click OK to save setting and back to upper level menu.
Task 2: Draw the Schedule
Steps:
1) Click to select a record type, including Continuous, Motion, Alarm, M | A, M & A, VCA and None.
To enable Motion, Alarm, M | A (motion or alarm), M & A (motion and alarm) and VCA (Video
Content Analysis) triggered recording and capture, you must configure the motion detection settings,
alarm input settings or VCA settings as well. For detailed information, refer to Chapter 8.1, Chapter
8.2 and Chapter 8.3.
The VCA settings are only available to the smart cameras supporting the VCA function.
Figure 5. 14 Draw the Schedule (1)
2) Use the mouse to drag and draw time periods.
Up to 8 periods can be configured for each day.
