User Manual of Digital Video Recorder
75
IP Camera is supported by HDVR series only.
5) Select the channels which you want the motion detection event to trigger recording or capture.
6) Click Apply to save the settings.
7) Click OK to back to the upper level menu.
8) Click Apply in the Motion Detection interface to save the settings. Exit the Motion Detection
interface.
3. Enter Record/Capture Schedule settings interface (Menu> Record> Schedule>Record/Capture Schedule).
For detailed information about record schedule settings, refer to step 2 in Chapter 5.2 Configuring
Record/Capture Schedule.
You need to select the Type as Motion in record schedule settings.
Figure 5. 21 Record Schedule
