Storage System User Manual
43
Add Master Hybrid SAN
3. Enter master Hybrid SAN IP address.
4. Click OK to add. The added master Hybrid SAN is listed in Hybrid SAN master list
5. Enter Maximum Taking Over Number and click Modify. If maximum taken-over master Hybrid SAN is 4 and
7 master Hybrid SANs are added, when 5 master Hybrid SANs are abnormal, the backup CVR would take over
the first added 4 master Hybrid SANs. After one or more of the 4 Hybrid SANs recovers, other master Hybrid
SANs would be taken over.
The max. taken-over number cannot be more than 10. If input 0 or input nothing, system regards it as 10.
Table 5. 3 Backup CVR Status
When master Hybrid SAN is normal, backup Hybrid SAN is standby.
When master Hybrid SAN is abnormal, backup CVR takes over the tasks. Now backup
Hybrid SAN status is working and master Hybrid SAN status is taken-over. When master
Hybrid SAN recovers, backup Hybrid SAN recovers to standby.
