Access Control Terminal·User Manual
92
The fingerprint associated functions are only supported by device with fingerprint recognition module
Manual Capture Configuration
The Manual Capture Configuration is for Access Control system to take photos remotely.
Auto Time Synchronization
Steps:
1. Open the System Configuration page.
2. Click the Common tab to enter the Common Settings interface.
3. Tick the checkbox to enable Auto Time Synchronization.
4. Select the matched day and input the time to operate the time adjustment.
5. Click the Save button to save the settings.
Note: You can click the Restore Default Value button to restore the defaults of all the local configurations.
Card Dispenser Configuration
Purpose:
The Card Reader Configuration of the Access Control System can configure device type, connection mode, serial port, baud rate and
other parameters of the Card Reader Configuration.
Steps:
1. Click the icon on the System Configuration interface to open the Card Dispatcher Configuration page.
2. Select the device type, serial port type, serial port, baud rate, and other parameters of the Card Dispatcher.
3. Click the save button to save the settings.
Notes:
It is supported using card type as regular and Wiegand.
When the BEEP is selected as “YES”, the audio will be off when you click the “SAVE” if the Card Reader Configuration is set
wrong; the audio will be on when you click the “Save” and when you insert the card reader if the configuration is set correct.
You can click the Restore Default Value button to restore the defaults of the entire local configuration.
Fingerprint Machine Configuration
Steps:
1. Click the icon on the System Configuration interface to open the Fingerprint Machine Configuration
page.
