Chapter 3 Installaon
3.1 Installaon Environment
●
Indoor use only.
●
Avoid backlight, direct sunlight, and indirect sunlight.
●
For beer recognion, there should be light source in or near the installaon environment.
●
The minimum bearing weight of the wall or other places should be 3 mes heavier than the
device weight.
3.2 Install with Gang Box
Steps
1.
Make sure the gang box is installed on the wall.
Note
You should purchase the gang box separately.
Figure 3-1 Install Gang Box
2.
Secur
e the mounng plate on the gang box with two supplied screws (SC-KA4X22).
Figure 3-2 Install Mounng Plate
3.
R
oute the cable through the cable hole, wire the cables and insert the cables in the gang box.
