If you select Opposite Lane, the lane direcon will be opposite from the current direcon.
Total Lanes
The sum of the linked lane(s) under the current applicaon mode.
Lane Direcon
The guidance direcon of the lane.
Lane Property
Select the lane type for speeding capture. The violaon rules vary with dierent lane types.
Direcon (in Mixed-Trac Lane Mode and Smart Mode)
The driving direcon of the vehicle. If you set the direcon as From Top to Boom, then the
vehicle will be judged as wrong-way driving if it comes from boom to top, and vice versa.
Direcon (in Video Analysis E-Police Mode)
The vehicles on the selected direcon will be detected.
1.5.3 Set
Connuous Capture Parameters
Set connuous capture parameters to realize the connuous capture of the violaon behaviors.
Steps
Note
●
Not all the applicaon modes support connuous capture parameters.
●
The connuous capture parameters vary with dierent models. The actual device prevails.
1.
Go to Conguraon → Capture → Applicaon Mode .
2.
Select Trigger Mode.
3.
Set connuous capture parameters.
Capture Pictures
The number of captured picture(s).
Occupy Emergency Lane Capture
Check it to capture emergency lane
occupaon violaon. One more picture will be captured
beyond the set number of captured picture(s).
Enable Low Speed Capture
Check it to capture the
violaon of driving in the speed lower than Min. Speed.
Speeding Capture
Check it to capture the speeding violaon. One more picture will be captured beyond the set
number of captured picture(s).
Capture Interval
Set Interval (dm) (the distance between the adjacent captures) if you select Distance, and set
Capture Interval (ms) (the me between the adjacent captures) if you select Time.
Network Trac Camera Conguraon Manual
25
