HIKVISION iDS-TCV507-BIR/1550 User Manual

Steps
1.
Click Radar.
2.
Click Coordinate Calibraon.
3.
Set the radar
calibraon.
-
Set manual calibraon. Refer to Manual Calibraon for details.
-
Set auto calibraon. Refer to Auto Calibraon for details.
Note
The supported calibraon modes vary with dierent models. The actual device prevails.
2.2.1 Manual Calibraon
Steps
1.
Click Coordinate
Calibraon.
2.
Select Calibraon Mode as Manual Calibraon.
Figure 2-3 Manual Calibraon
3.
Draw the lane lines.
1) Select the lane sum.
2) Select the lane line No.
3) Click Draw Lane Line.
The selected lane line will be displayed on the live view picture.
4) Drag the two end points of the line or drag the whole line to adjust its
posion according to
the actual scene.
5) Repeat the steps above to draw more lane lines.
4.
Draw the
calibraon area.
1) Select Calibraon Point.
Network Trac Camera Conguraon Manual
56
