2.
Select Trigger Mode.
3.
Set the lane speed limit parameters for small-sized and large-sized vehicles.
Abnormal Low Speed
When the detected speed of the vehicle is lower than the value, the detecon is regarded as
abnormal, and a normal speed will be provided randomly.
Min. Speed
The actual allowed min. speed for the vehicles. When the vehicle speed is lower than the
value, low speed capture will be triggered.
Note
The min. speed of large-sized vehicles should be smaller than that of the small-sized vehicles.
Speed Limit Sign
The speed limit on the sign for the vehicles. The value will be overlaid on the captured
pictures.
Speed Limit
The actual speed limit for the vehicles. When the vehicle speed exceeds the value, speeding
capture will be triggered.
Note
The speed limit of large-sized vehicles should be smaller than that of the small-sized vehicles.
Abnormal Speed Threshold
When the detected speed of the vehicle exceeds the value, the detecon is regarded as
abnormal, and a normal speed will be provided randomly.
Capture Speed
When the speed of the vehicle on the lane (except the emergency lane) is lower than the set
value, no capture will be triggered.
4.
Click Save.
1.5.10 Set
Trac Light Detecon Parameters
Trac light detecon is supported for video analysis intersecon violaon system.
Steps
1.
Go to Conguraon → Capture → Applicaon Mode .
2.
Select Trigger Mode as Video Analysis E-Police.
3.
Select
Trac Light Signal Input and set the corresponding parameters.
RS-485
Set Linked Red Light Channel and Yellow Light Related Channel No. according to
the actual wiring.
Network Trac Camera Conguraon Manual
31
