User Manual of Network Camera
141
1) To edit the arming schedule, click Edit button.
2) Choose the day you want to set the arming schedule.
3) Click to set the time period for the arming schedule.
4) (Optional) After you set the arming schedule, you can click the Copy button
to copy the schedule to other days.
5) Click OK to save the settings.
Note: The time of each period cannot be overlapped.
8. Check the checkbox to select the linkage method. Notify surveillance center and
upload to FTP are selectable.
Notify Surveillance Center: Send an exception or alarm signal to remote
management software when an event occurs.
Upload to FTP: Capture the image when an alarm is triggered and upload the
picture to a FTP server. And save the picture on the local SD card or connected
NAS.
9. Click Save to save the settings.
Figure 9-1 Vehicle Detection Configuration
