Function Checks
Chapter 2: Troubleshooting Procedures
b. Place the skin probe 4" (10 cm) above the center of the mattress.
c. Set the skin set temperature to 95°F (35°C).
d. When the temperature stabilizes, open the access panel (F).
In approximately 5 min, the alarm indicators activate, the Low Skin
Temperature message appears in place of the Trend display, and the alarm
sounds.
Yes No
ψ — Goto RAP 2.1.
NOTE:
The sensor module is equipped to accept two skin probes. However, when the
second skin probe is connected to the sensor module in Skin Mode, an alarm
sounds, and the message Remove Skin 2 Probe appears. In order to connect
the second skin probe, first select Air Mode, and then the controller displays
the two temperatures.
25. Check the Connect Skin 1 Probe alarm.
a. Remove the skin probe #2 from the sensor module (C).
b. Select Skin Mode.
c. Disconnect the skin probe #1 from the sensor module (C). The alarm
sounds, and the Skin Temperature display goes blank.
d. The message Connect Skin 1 Probe appears.
e. Press the Silence/Reset key. The alarm goes silent for 5 min.
Connect a skin probe. The incubator returns to normal operation.
Yes No
4 — Сою ВАР 2.1.
26. Check the maximum air temperature.
a. Connect a skin probe to the sensor module (C), and select Skin Mode
and a temperature of greater than 99°F (37°C).
b. Place the skin probe sensor outside the incubator.
c. Allow the incubator to heat.
d. If the Skin Temperature alarm sounds, press the Silence/Reset key.
The incubator’s temperature stays below 103.8°F (39.9°C) as indicated by
the Air Temperature display.
Yes No
y > Goto RAP 2.1.
Page 2 - 12 Isolette® infant Incubator Service Manual (man223rf)
