Hill-Rom VersaCare P3201 User Manual

4.2 Caster
Chapter 4: Removal, Replacement, and Adjustment Procedures
Replacement
NOTE:
The new caster comes in the neutral position.
1. For foot end casters, do the following:
a. Using the brake/steer pedal (E), set the caster to the brake position.
b. Position the new caster so the alignment pin (O) will fit into the slot
(P).
c. Insert the caster (F) into the bed.
d. Install the brake/steer pedal (E) through the caster (F) and clamp (D).
e. Tighten the nut (C).
f. Install the foot end cover (B).
g. Install the screw (A) to secure the foot end cover (B) to the bed.
h. To make sure the VersaCare™ Bed operates correctly, do the
“Function Checks” on page 2-6.
2. For head end casters, do the following:
a. Using the brake/steer pedal (E), set the caster to the brake position.
b. Position the new caster so the alignment pin (O) will fit into the slot
(P).
c. Insert the caster (N) into the bed.
d. Install the brake/steer pedal (M) through the caster (N) and clamp (L)
into the torque tube (J).
e. Tighten the setscrew (I).
f. Tighten the nut (K).
g. Install the head end cover (H).
h. Install the screw (G).
i. To make sure the VersaCare™ Bed operates correctly, do the
“Function Checks” on page 2-6.
4
VersaCare™ Bed Service Manual (MAN333 REV 2) Page 4 - 7
