4.8 Patient Control P.C. Board
Chapter 4: Removal, Replacement, and Adjustment Procedures
4.8 Patient Control P.C. Board
Tools required: T20 Torx®
1
screwdriver
T15 Torx® screwdriver
7/64" drill bit
Drill
#6-32 tap
Removal
1. Set the brakes.
2. Raise the bed to the high position.
3. Raise the appropriate siderail to the up and locked position.
SHOCK HAZARD:
Unplug the bed from its power source. Failure to do so could result in
personal injury or equipment damage.
4. Unplug the bed from its power source.
5. Drill a hole in the center of each screw cover (A) (see figure 4-11 on page
4-25).
6. Using the tap, remove the screw covers (A).
7. Remove the 12 screws (B).
8. Remove the siderail cover (C) from the siderail (D).
9. Put the siderail cover (C) on the bed.
10. Remove the four screws (E) from the siderail P.C. board (F).
11. Fold down the P.C. board (F).
12. Remove the six screws (G) securing the stiffener (H) to the siderail (D).
13. Remove the stiffener (H).
14. Remove the four screws (I) securing the patient control P.C. board (J) to
the siderail (D).
1. Torx® is a registered trademark of Textron, Inc.
Page 4 - 24 VersaCare™ Bed Service Manual (MAN333 REV 2)
