Specifications
Chapter 1: Introduction
1
Electrical Description
AC Power Requirements
Nominal Power
Distribution Voltage
(Volts)
Nominal Power
Distribution Frequency
(Hertz)
Maximum Equipment
Current (Amps)
120 (P3200) 60
6.0
a
100/110/115/120/127
(P3201)
50/60 6.0
220/230/240 (P3201) 50/60 3.0
a. North American power supply configuration.
Fuse Specifications
Condition Range
Battery fuse 250 V, 15 A fast blow, 3AB
Mains fuse (100/110/115/120/127 V mod-
els)
125 V~, 5 A time delay, 5 x 20 mm (2
each), UL 198G Slo-Blo®
a
Mains fuse (220/230/240 V models) 250 V~, 2.5 A, time delay, 5 x 20 mm (2
each), IEC
Transformer Secondary #1 250 V~, 20 A, Slo-Blo®, 3AB
a. Slo-Blo® is a registered trademark of Littelfuse, Inc.
Regulations, Standards, and Codes
For VersaCare™ Bed regulations, standards and codes, see table 1-2 on page
1-7.
Table 1-2. Classification and Standards:
Technical and Quality Assurance Stan-
dards
UL 60601-1
CSA®
a
C22.2 No. 601.1
IEC 60601-2-38
EN 60601-1
IEC 60601-1-4
EN ISO 9001 and EN 13485
VersaCare™ Bed Service Manual (MAN333 REV 2) Page 1 - 7
