Permanent IV Pole
Chapter 5: Parts List
Permanent IV Pole
Figure 5-24. Permanent IV Pole
Table 5-24. Permanent IV Pole
Item Number Part Number Quantity Description
71623 (3200) 2 Bracket
72220 (3200) 1 IV hook rest
4604601 (3200) 1 Pin
72219 (3200) 2 Weldment, IV support
71651 (3200) 1 Weldment, IV Pole mount
72323 (3200) 1 Weldment, ISS socket
126378 (3200) 1 Permanent IV Pole assembly
70341 (3200) 6 Screw
70428 (3200) 4 Nut
70342 (3200) 4 Screw
11 38129 (3200) 1 Chain and knob assembly
Page 5 - 62 VersaCare™ Bed Service Manual (MAN333 REV 2)
