Hill-Rom VersaCare P3201 User Manual

4.3 CPR Cable
Chapter 4: Removal, Replacement, and Adjustment Procedures
4.3 CPR Cable
Tools required: T25 Torx®
1
screwdriver
7 mm wrench
Removal
1. Set the brakes.
2. Raise the bed to the high position.
3. Raise the head section to the highest position.
SHOCK HAZARD:
Unplug the bed from its power source. Failure to do so could result in
personal injury or equipment damage.
4. Unplug the bed from its power source.
5. Loosen the jam nut (A) (see figure 4-4 on page 4-9).
6. Remove the CPR cable hook (B) from the handle bracket (C).
7. Remove the nut (D).
8. Remove the CPR cable (E) from the mount bracket (F).
9. Remove the two screws (G) from the CPR release cover (H).
10. Slide the CPR release cover (H) down.
11. Remove the CPR cable (E) from the CPR release (I).
12. Cut and remove the two cable ties (J) securing the CPR cable (E) to the
head section (K).
13. Remove the CPR cable from the head section.
1. Torx® is a registered trademark of Textron, Inc.
Page 4 - 8 VersaCare™ Bed Service Manual (MAN333 REV 2)
